S-Plastics Lexan ML3940 resin is a highly UV stabilised grade which has been developed as a coextrusion product exhibiting a low plate out behaviour and improved outdoor weathering of LEXAN sheet.
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield, 50 mm/min | 63 | MPa | ISO 527 |
| Tensile Stress, break, 50 mm/min | 70 | MPa | ISO 527 |
| Tensile Strain, yield, 50 mm/min | 6 | % | ISO 527 |
| Tensile Strain, break, 50 mm/min | 120 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 2350 | MPa | ISO 527 |
| Flexural Stress, yield, 2 mm/min | 90 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 2300 | MPa | ISO 178 |
| THERMAL | Value | Unit | Standard |
| Vicat Softening Temp, Rate B/120 | 135 | °C | ISO 306 |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.2 | g/cm³ | ISO 1183 |
| Melt Volume Rate, MVR at 300°C/1.2 kg | 10 | cm³/10 min | ISO 1133 |
| Source GMD, last updated:03/13/2001 | |||
| Profile Extrusion | Value | Unit | |
| Drying Temperature | 105 | °C | |
| Drying Time | 2 - 3 | hrs | |
| Melt Temperature | 220 - 250 | °C | |
| Barrel - Zone 1 Temperature | 240 - 280 | °C | |
| Barrel - Zone 2 Temperature | 240 - 280 | °C | |
| Barrel - Zone 3 Temperature | 220 - 240 | °C | |
| Barrel - Zone 4 Temperature | 220 - 240 | °C | |
| Hopper Temperature | 60 - 80 | °C | |
| Adapter Temperature | 220 - 240 | °C | |
| Die Temperature | 245 - 290 | °C | |
| Calibrator Temperature | 60 - 100 | °C | |
| Source GMD, last updated:03/13/2001 | |||
| THESE PROPERTY VALUES ARE NOT INTENDED FOR SPECIFICATION PURPOSES. | |||
| PLEASE CHECK WITH YOUR (LOCAL SALES OFFICE) FOR AVAILABILITY IN YOUR REGION | |||
| (1) Typical values only. Variations within normal tolerances are possible for various colors. All values are measured after at least 48 hours storage at 23°C/50% relative humidity. All properties, except the melt volume and melt flow rates, are measured on injection molded samples. All samples tested under ISO test standards are prepared according to ISO 294. |
|||
| (2) Only typical data for selection purposes. Not to be used for part or tool design. | |||
| (3) This rating is not intended to reflect hazards presented by this or any other material under actual fire conditions. | |||
| (4) Internal measurements according to UL standards. | |||
|
