S-Plastics NoryL EXNL1116 resin is Flexible, non-halogenated FR, mPPE extrusion grade material for evaluation in automotive wire coating applications requiring ISO6722.
Property
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 50 mm/min | 28 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 50 mm/min | 27 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 50 mm/min | 30 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 50 mm/min | 60 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 950 | MPa | ASTM D 638 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 730 | MPa | ASTM D 790 |
| Hardness, Shore D, 10S reading | 63 | - | ASTM D 2240 |
| Tensile Stress, yield | 28 | MPa | ISO 527 |
| Tensile Stress, break, 50 mm/min | 27 | MPa | ISO 527 |
| Tensile Strain, yield, 50 mm/min | 40 | % | ISO 527 |
| Tensile Strain, break, 50 mm/min | 50 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 990 | MPa | ISO 527 |
| Flexural Stress | 28 | MPa | ISO 178 |
| Flexural Modulus | 920 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 430 | J/m | ASTM D 256 |
| Izod Impact, notched, -30°C | 160 | J/m | ASTM D 256 |
| Izod Impact, notched 80*10*4 +23°C | 42 | kJ/m² | ISO 180/1A |
| Izod Impact, notched 80*10*4 -30°C | 10 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 82 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 3.2mm, unannealed | 56 | °C | ASTM D 648 |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 66 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.03 | - | ASTM D 792 |
| Melt Flow Rate, 280°C/5.0 kgf | 32 | g/10 min | ASTM D 1238 |
| ELECTRICAL | Value | Unit | Standard |
| Relative Permittivity, 1 GHz | 2.47 | - | ASTM D 150 |
| Dissipation Factor, 1 GHz | 0.0032 | - | ASTM D 150 |
| Source GMD, last updated:09/26/2008 | |||
| Parameter | |||
| Wire Coating Extrusion | Value | Unit | |
| Drying Temperature | 60 - 80 | °C | |
| Drying Time | 4 - 6 | hrs | |
| Drying Time (Cumulative) | 12 | hrs | |
| Maximum Moisture Content | 0.02 | % | |
| Extruder Length/Diameter Ratio (L/D) | 22:1 to 26:1 | - | |
| Screw Speed | 15 - 40 | rpm | |
| Feed Zone Temperature | 210 - 260 | °C | |
| Middle Zone Temperatures | 230 - 285 | °C | |
| Head Zone Temperature | 250 - 285 | °C | |
| Neck Temperature | 250 - 285 | °C | |
| Cross-head Temperature | 250 - 285 | °C | |
| Die Temperature | 250 - 285 | °C | |
| Melt Temperature | 250 - 285 | °C | |
| Conductor Pre-heat Temperature | 80 - 150 | °C | |
| Screen Pack | 150 - 100 | - | |
| Cooling Water Air Gap | 100 - 200 | mm | |
| Water Bath Temperature | 15 - 80 | °C | |
| Source GMD, last updated:09/26/2008 | |||
Other related products we recommend:
Drinking water / food grade:731,731S,GFN10F,GFN20F,GFN30F,GFN1520V,GFN1630V(Color requirements)
Unreinforce and flame retardant: 0150B,N190X,PX9406P,SE100X
Reinforce and flame retardant: SE1GFN1,SE1GFN2,SE1GFN3,HS2000X
|
For more information please see below |
|
 |
S-Plastics Noryl EXNL1116.pdf |
|
Get The Latest Quotation 5000 kinds of products 1000 tons of spot inventory First-level distribution source in South China Reduce procurement costs, improve supply stability, Help you find the most suitable engineering plastic materials
|
|
S-Plastics Noryl Resin Application
|
S-Plastics Noryl PPO is modified polyphenylene oxide (PPO) resins produced by the S-Plastics company. It is known for its excellent balance of properties, including high heat resistance, dimensional stability, and chemical resistance.
Noryl PPO resins are produced by blending PPO with other materials, such as polystyrene or polyamide.S-Plastics Noryl PPO include: |
|
|
| 3. Chemical resistance: S-Plastics Noryl PPO has good chemical resistance. It is commonly used in automotive and electrical applications where chemical resistance is important. 4. Good electrical properties: S-Plastics Noryl PPO has good electrical properties. This makes it suitable for use in electrical and electronic applications, such as connectors and switches. 5. Ease of processing: S-Plastics Noryl PPO is easy to process and can be easily molded into complex shapes with thin walls. |
||
