S-Plastics Noryl EXNX0047 resin is resin is a high performance blend of PPE/PA that exhibits an excellent balance of non-halogenated flame
retardance, conductivity, ductility, and high-heat resistance. This grade is designed for profile extrusion and can be electro-statically painted or powder coated without the need for a conductive primer.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 50 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 5 mm/min | 45 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 5 mm/min | 7 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 12 | % | ASTM D 638 |
| Tensile Modulus, 5 mm/min | 2500 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 84 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 2300 | MPa | ASTM D 790 |
| Tensile Stress, yield, 5 mm/min | 50 | MPa | ISO 527 |
| Tensile Stress, break, 5 mm/min | 45 | MPa | ISO 527 |
| Tensile Strain, yield, 5 mm/min | 7 | % | ISO 527 |
| Tensile Strain, break, 5 mm/min | 12 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 2500 | MPa | ISO 527 |
| Flexural Stress, yield, 2 mm/min | 84 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 2300 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 1200 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 82 | J/m | ASTM D 256 |
| Izod Impact, notched, -30°C | 62 | J/m | ASTM D 256 |
| Izod Impact, unnotched 80*10*4 +23°C | 70 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 10 | kJ/m² | ISO 180/1A |
| Izod Impact, notched 80*10*4 -30°C | 7 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 193 | °C | ASTM D 648 |
| Specific Heat | 1.4 | J/g-°C | ASTM C 351 |
| Thermal Conductivity | 0.2 | W/m-°C | ASTM C 177 |
| CTE, 23°C to 60°C, flow | 8.3E+00 | 1/°C | ISO 11359-2 |
| CTE, 23°C to 60°C, xflow | 8.5E+00 | 1/°C | ISO 11359-2 |
| Ball Pressure Test, 125°C +/- 2°C | Pass | - | IEC 60695-10-2 |
| Vicat Softening Temp, Rate B/120 | 194 | °C | ISO 306 |
| HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm | 191 | °C | ISO 75/Bf |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.12 | - | ASTM D 792 |
| Melt Flow Rate, 300°C/5.0 kgf | 7.8 | g/10 min | ASTM D 1238 |
| Density | 1.12 | g/cm³ | ISO 1183 |
| Melt Volume Rate, MVR at 300°C/5.0 kg | 7 | cm³/10 min | ISO 1133 |
| ELECTRICAL | Value | Unit | Standard |
| Volume Resistivity | 4.E+03 | Ohm-cm | ASTM D 257 |
| FLAME CHARACTERISTICS | Value | Unit | Standard |
| UL Compliant, 94V-1 Flame Class Rating (3)(4) | 1.5 | mm | UL 94 by GE |
| UL Compliant, 94V-0 Flame Class Rating (3)(4) | 2 | mm | UL 94 by GE |
| Glow Wire Flammability Index 750°C, passes at | 1 | mm | IEC 60695-2-12 |
| Glow Wire Flammability Index 850°C, passes at | 2 | mm | IEC 60695-2-12 |
| Glow Wire Flammability Index 960°C, passes at | 2.5 | mm | IEC 60695-2-12 |
| Source GMD, last updated:11/07/2005 | |||
| Parameter | ||
| Profile Extrusion | Value | Unit |
| Drying Temperature | 105 - 110 | °C |
| Drying Time | 8 | hrs |
| Drying Time (Cumulative) | 24 | hrs |
| Maximum Moisture Content | 0.03 | % |
| Melt Temperature | 245 - 260 | °C |
| Barrel - Zone 1 Temperature | 245 - 260 | °C |
| Barrel - Zone 2 Temperature | 245 - 260 | °C |
| Barrel - Zone 3 Temperature | 245 - 260 | °C |
| Barrel - Zone 4 Temperature | 245 - 260 | °C |
| Adapter Temperature | 245 - 260 | °C |
| Die Temperature | 245 - 260 | °C |
| Calibrator Temperature | 35 - 75 | °C |
| Water Bath Temperature | 40 - 50 | °C |
| Source GMD, last updated:11/07/2005 | ||
|
For more information please see below |
|
 |
S-Plastics Noryl EXNX0047.pdf |
|
Get The Latest Quotation 5000 kinds of products 1000 tons of spot inventory First-level distribution source in South China Reduce procurement costs, improve supply stability, Help you find the most suitable engineering plastic materials
|
|
S-Plastics Noryl Resin Application
|
S-Plastics Noryl PPO is modified polyphenylene oxide (PPO) resins produced by the S-Plastics company. It is known for its excellent balance of properties, including high heat resistance, dimensional stability, and chemical resistance.
Noryl PPO resins are produced by blending PPO with other materials, such as polystyrene or polyamide.S-Plastics Noryl PPO include: |
|
|
| 3. Chemical resistance: S-Plastics Noryl PPO has good chemical resistance. It is commonly used in automotive and electrical applications where chemical resistance is important. 4. Good electrical properties: S-Plastics Noryl PPO has good electrical properties. This makes it suitable for use in electrical and electronic applications, such as connectors and switches. 5. Ease of processing: S-Plastics Noryl PPO is easy to process and can be easily molded into complex shapes with thin walls. |
||
