S-Plastics Noryl EXNX0097 resin is resin is a high performance alloy of polyphthalamide and PPE. This grade exhibits high heat resistance suitable for lead-free soldering or IR re-flow applications. This grade is non-halogenated flame retardant.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Strain, yld, Type I, 5 mm/min | 2 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 2 | % | ASTM D 638 |
| Tensile Stress, break, 5 mm/min | 150 | MPa | ISO 527 |
| Tensile Strain, break, 5 mm/min | 2 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 12000 | MPa | ISO 527 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 65 | J/m | ASTM D 256 |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 3.2mm, unannealed | 262 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 6.4 mm, unannealed | 265 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, flow | 2.1E+00 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, xflow | 5.6E+00 | 1/°C | ASTM E 831 |
| Vicat Softening Temp, Rate B/120 | 255 | °C | ISO 306 |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.47 | - | ASTM D 792 |
| Mold Shrinkage, flow, 3.2 mm | 0.16 - 0.2 | % | S-Plastics Method |
| Mold Shrinkage, xflow, 3.2 mm | 0.34 - 0.38 | % | S-Plastics Method |
| Melt Flow Rate, 330°C/2.16 kgf | 7.4 | g/10 min | ASTM D 1238 |
| Density | 1.47 | g/cm³ | ISO 1183 |
| Water Absorption, 23°C/24hrs | 0.19 | % | ISO 62-1 |
| Water Absorption, (23°C/sat) | 1 | % | ISO 62 |
| Moisture Absorption, 50% RH, 24hrs | 0.08 | % | ISO 62-4 |
| Melt Volume Rate, MVR at 330°C/2.16kg | 5 | cm³/10 min | ISO 1133 |
| Source GMD, last updated:01/07/2008 | |||
| THESE PROPERTY VALUES ARE NOT INTENDED FOR SPECIFICATION PURPOSES. | |||
| PLEASE CHECK WITH YOUR (LOCAL SALES OFFICE) FOR AVAILABILITY IN YOUR REGION | |||
| (1) Typical values only. Variations within normal tolerances are possible for various colors. All values are measured after at least 48 hours storage at 23°C/50% relative humidity. All properties, except the melt volume and melt flow rates, are measured on injection molded samples. All samples tested under ISO test standards are prepared according to ISO 294. |
|||
| (2) Only typical data for selection purposes. Not to be used for part or tool design. | |||
| (3) This rating is not intended to reflect hazards presented by this or any other material under actual fire conditions. | |||
| (4) Internal measurements according to UL standards. | |||
|
For more information please see below |
|
 |
S-Plastics Noryl EXNX0097.pdf |
|
Get The Latest Quotation 5000 kinds of products 1000 tons of spot inventory First-level distribution source in South China Reduce procurement costs, improve supply stability, Help you find the most suitable engineering plastic materials
|
|
S-Plastics Noryl Resin Application
|
S-Plastics Noryl PPO is modified polyphenylene oxide (PPO) resins produced by the S-Plastics company. It is known for its excellent balance of properties, including high heat resistance, dimensional stability, and chemical resistance.
Noryl PPO resins are produced by blending PPO with other materials, such as polystyrene or polyamide.S-Plastics Noryl PPO include: |
|
|
| 3. Chemical resistance: S-Plastics Noryl PPO has good chemical resistance. It is commonly used in automotive and electrical applications where chemical resistance is important. 4. Good electrical properties: S-Plastics Noryl PPO has good electrical properties. This makes it suitable for use in electrical and electronic applications, such as connectors and switches. 5. Ease of processing: S-Plastics Noryl PPO is easy to process and can be easily molded into complex shapes with thin walls. |
||
