S-Plastics Thermocom OB008 resin is Glass Bead Filled, PPS
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 40 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 5 mm/min | 40 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 5 mm/min | 1.7 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 1.8 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 6630 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 87 | MPa | ASTM D 790 |
| Flexural Stress, brk, 1.3 mm/min, 50 mm span | 87 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 5920 | MPa | ASTM D 790 |
| Tensile Stress, yield, 5 mm/min | 47 | MPa | ISO 527 |
| Tensile Stress, break, 5 mm/min | 46 | MPa | ISO 527 |
| Tensile Strain, yield, 5 mm/min | 1 | % | ISO 527 |
| Tensile Strain, break, 5 mm/min | 1.3 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 6330 | MPa | ISO 527 |
| Flexural Stress, yield, 2 mm/min | - | MPa | ISO 178 |
| Flexural Strain, break, 2 mm/min | 1.7 | % | ISO 178 |
| Flexural Modulus, 2 mm/min | 6170 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 147 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 31 | J/m | ASTM D 256 |
| Multiaxial Impact | 1 | J | ISO 6603 |
| Izod Impact, unnotched 80*10*4 +23°C | 9 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 3 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 218 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 3.2mm, unannealed | 115 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, flow | 4.3E+01 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, xflow | 4.14E+01 | 1/°C | ASTM E 831 |
| HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm | 202 | °C | ISO 75/Bf |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 121 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.635 | g/cm³ | ASTM D 792 |
| Moisture Absorption, 50% RH, 24 hrs | 0.01 | % | ASTM D 570 |
| Mold Shrinkage, flow, 24 hrs | 0.92 - 0.94 | % | ASTM D 955 |
| Mold Shrinkage, xflow, 24 hrs | 0.92 - 0.94 | % | ASTM D 955 |
| Density | 1.63 | g/cm³ | ISO 1183 |
| Moisture Absorption (23°C / 50% RH) | 0.01 | % | ISO 62 |
| ELECTRICAL | Value | Unit | Standard |
| Dissipation Factor, 50/60 Hz | - | - | ASTM D 150 |
| Source GMD, last updated:12/18/2007 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 120 - 150 | °C |
| Drying Time | 4 | hrs |
| Melt Temperature | 315 - 320 | °C |
| Front - Zone 3 Temperature | 330 - 345 | °C |
| Middle - Zone 2 Temperature | 320 - 330 | °C |
| Rear - Zone 1 Temperature | 305 - 315 | °C |
| Mold Temperature | 140 - 165 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 30 - 60 | rpm |
| Source GMD, last updated:12/18/2007 | ||
