S-Plastics Thermocomp OF002A resin is a compound based on Polyphenylene Sulfide resin containing Glass Fiber.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield | 48 | MPa | ASTM D 638 |
| Tensile Stress, break | 48 | MPa | ASTM D 638 |
| Tensile Strain, yield | 0.6 | % | ASTM D 638 |
| Tensile Strain, break | 0.6 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 8960 | MPa | ASTM D 638 |
| Flexural Stress | 82 | MPa | ASTM D 790 |
| Flexural Modulus | 6200 | MPa | ASTM D 790 |
| Tensile Stress, yield | 49 | MPa | ISO 527 |
| Tensile Stress, break | 49 | MPa | ISO 527 |
| Tensile Strain, yield | 0.6 | % | ISO 527 |
| Tensile Strain, break | 0.6 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 7150 | MPa | ISO 527 |
| Flexural Stress | 98 | MPa | ISO 178 |
| Flexural Modulus | 6400 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 90 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 32 | J/m | ASTM D 256 |
| Multiaxial Impact | 1 | J | ISO 6603 |
| Izod Impact, unnotched 80*10*4 +23°C | 6 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 3 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 271 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 3.2mm, unannealed | 235 | °C | ASTM D 648 |
| HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm | 272 | °C | ISO 75/Bf |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 228 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.42 | g/cm³ | ASTM D 792 |
| Mold Shrinkage, flow, 24 hrs | 0.9 - 1.1 | % | ASTM D 955 |
| Mold Shrinkage, xflow, 24 hrs | 0.9 - 1.1 | % | ASTM D 955 |
| Mold Shrinkage, flow, 24 hrs | 1 | % | ISO 294 |
| Mold Shrinkage, xflow, 24 hrs | 1 | % | ISO 294 |
| Density | 1.41 | g/cm³ | ISO 1183 |
| Source GMD, last updated:09/24/2008 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 120 - 150 | °C |
| Drying Time | 4 | hrs |
| Melt Temperature | 315 - 320 | °C |
| Front - Zone 3 Temperature | 330 - 345 | °C |
| Middle - Zone 2 Temperature | 320 - 330 | °C |
| Rear - Zone 1 Temperature | 305 - 315 | °C |
| Mold Temperature | 140 - 165 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 30 - 60 | rpm |
| Source GMD, last updated:09/24/2008 | ||
