S-Plastics Thermocomp RX07034 resin is a compound based on PA 66 resin containing Glass Fiber. Added features include; Low Smoke, EasyMolding, Cross Linkable under Beta-or Gamma Radiation; Specially developed for Arc chambers.
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, break, 5 mm/min | 170 | MPa | ISO 527 |
| Tensile Strain, break, 5 mm/min | 2.3 | % | ISO 527 |
| Flexural Stress, break, 2 mm/min | 225 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 9500 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched 80*10*4 +23°C | 60 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 9 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 213 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Mold Shrinkage, flow (5) | 0.3 - 0.5 | % | S-Plastics Method |
| Density | 1.54 | g/cm³ | ISO 1183 |
| FLAME CHARACTERISTICS | Value | Unit | Standard |
| UL Compliant, 94HB Flame Class Rating (3)(4) | 1.6 | mm | UL 94 by GE |
| Source GMD, last updated:2008/12/05 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 80 | °C |
| Drying Time | 4 | hrs |
| Maximum Moisture Content | 0.2 | % |
| Melt Temperature | 270 - 290 | °C |
| Front - Zone 3 Temperature | 280 - 290 | °C |
| Middle - Zone 2 Temperature | 265 - 285 | °C |
| Rear - Zone 1 Temperature | 260 - 280 | °C |
| Mold Temperature | 60 - 90 | °C |
| Back Pressure | >1 | MPa |
| Screw Speed | 80 - 120 | rpm |
| Source GMD, last updated:2008/12/05 | ||
