S-Plastics Thermocomp 2X03624H resin is a compound based on FEP resin containing Mineral.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield | 13 | MPa | ASTM D 638 |
| Tensile Stress, break | NB | MPa | ASTM D 638 |
| Tensile Strain, yield | 9.3 | % | ASTM D 638 |
| Tensile Strain, break | NB | % | ASTM D 638 |
| Flexural Stress | 13 | MPa | ASTM D 790 |
| Flexural Modulus | 620 | MPa | ASTM D 790 |
| Tensile Stress, yield | 14 | MPa | ISO 527 |
| Tensile Stress, break | NB | MPa | ISO 527 |
| Tensile Strain, yield | 7.2 | % | ISO 527 |
| Tensile Strain, break | NB | % | ISO 527 |
| Flexural Stress | 16 | MPa | ISO 178 |
| Flexural Modulus | 600 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | NB | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 566 | J/m | ASTM D 256 |
| Instrumented Impact Energy @ peak, 23°C | 30 | J | ASTM D 3763 |
| Multiaxial Impact | 46 | J | ISO 6603 |
| Izod Impact, unnotched 80*10*4 +23°C | NB | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 64 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 3.2mm, unannealed | 53 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, flow | 1.21E-04 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, xflow | 1.26E-04 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, flow | 1.21E-04 | 1/°C | ISO 11359-2 |
| CTE, -40°C to 40°C, xflow | 1.28E-04 | 1/°C | ISO 11359-2 |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 58 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 2.23 | g/cm³ | ASTM D 792 |
| Mold Shrinkage, flow, 24 hrs | 3.9 | % | ASTM D 955 |
| Mold Shrinkage, xflow, 24 hrs | 4.5 | % | ASTM D 955 |
| Mold Shrinkage, flow, 24 hrs | 3.89 | % | ISO 294 |
| Mold Shrinkage, xflow, 24 hrs | 4.49 | % | ISO 294 |
| Density | 2.22 | g/cm³ | ISO 1183 |
| Moisture Absorption (23°C / 50% RH) | 0.03 | % | ISO 62 |
| Source GMD, last updated:09/24/2008 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 120 - 150 | °C |
| Drying Time | 4 | hrs |
| Melt Temperature | 345 | °C |
| Front - Zone 3 Temperature | 360 - 370 | °C |
| Middle - Zone 2 Temperature | 340 - 350 | °C |
| Rear - Zone 1 Temperature | 315 - 325 | °C |
| Mold Temperature | 140 - 165 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 30 - 60 | rpm |
| Source GMD, last updated:09/24/2008 | ||
