S-Plastics Cycolac AL003 resin is
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield | 35 | MPa | ASTM D 638 |
| Tensile Stress, break | 32 | MPa | ASTM D 638 |
| Tensile Strain, yield | 2.3 | % | ASTM D 638 |
| Tensile Strain, break | 14.7 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 2410 | MPa | ASTM D 638 |
| Flexural Stress | 62 | MPa | ASTM D 790 |
| Flexural Modulus | 2060 | MPa | ASTM D 790 |
| Tensile Stress, yield | 35 | MPa | ISO 527 |
| Tensile Stress, break | 32 | MPa | ISO 527 |
| Tensile Strain, yield | 2.7 | % | ISO 527 |
| Tensile Strain, break | 11.6 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 2280 | MPa | ISO 527 |
| Flexural Stress | 61 | MPa | ISO 178 |
| Flexural Modulus | 2000 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 202 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 58 | J/m | ASTM D 256 |
| Instrumented Impact Energy @ peak, 23°C | 11 | J | ASTM D 3763 |
| Multiaxial Impact | 8 | J | ISO 6603 |
| Izod Impact, unnotched 80*10*4 +23°C | 21 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 5 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 3.2mm, unannealed | 77 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, flow | 9.54E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, xflow | 9.36E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, flow | 9.57E-05 | 1/°C | ISO 11359-2 |
| CTE, -40°C to 40°C, xflow | 9.5E-05 | 1/°C | ISO 11359-2 |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 81 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.13 | g/cm³ | ASTM D 792 |
| Moisture Absorption, 50% RH, 24 hrs | 0.2 | % | ASTM D 570 |
| Mold Shrinkage, flow, 24 hrs | 0.6 - 0.8 | % | ASTM D 955 |
| Mold Shrinkage, xflow, 24 hrs | 0.8 - 1 | % | ASTM D 955 |
| Mold Shrinkage, flow, 24 hrs | 0.6 - 0.8 | % | ISO 294 |
| Mold Shrinkage, xflow, 24 hrs | 0.8 - 1 | % | ISO 294 |
| Wear Factor Washer | 100 | 10^-10 in^5-min/ft-lb-hr | ASTM D 3702 Modified |
| Dynamic COF | 0.22 | - | ASTM D 3702 Modified |
| Static COF | 0.11 | - | ASTM D 3702 Modified |
| Density | 1.13 | g/cm³ | ISO 1183 |
| Moisture Absorption (23°C / 50% RH) | 0.31 | % | ISO 62 |
| Source GMD, last updated:12/16/2004 |
