S-Plastics Lubricomp Cycoloy_C2801R resin is LNP* Lubricomp* Cycoloy_C2801R compound is a 5% PTFE reinforced PC+ABS wear resistant, flame retardant compound for moving
components in business equipment. 30% recycle content.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 50 mm/min | 62 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 50 mm/min | 51 | MPa | ASTM D 638 |
| Tensile Strain, brk, Type I, 50 mm/min | 110 | % | ASTM D 638 |
| Flexural Stress, yld, 2.6 mm/min, 100 mm span | 95 | MPa | ASTM D 790 |
| Flexural Modulus, 2.6 mm/min, 100 mm span | 2720 | MPa | ASTM D 790 |
| K-factor xE-10, PV=2000 psi-fpm vs Steel | 430 | - | S-Plastics Method |
| Coefficient of Friction on steel, Static | 0.16 | - | ASTM D 1894 |
| Coefficient of Friction on steel,Kinetic | 0.21 | - | ASTM D 1894 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 133 | J/m | ASTM D 256 |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 6.4 mm, unannealed | 82 | °C | ASTM D 648 |
| Relative Temp Index, Elec | 60 | °C | UL 746B |
| Relative Temp Index, Mech w/impact | 60 | °C | UL 746B |
| Relative Temp Index, Mech w/o impact | 60 | °C | UL 746B |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.22 | - | ASTM D 792 |
| ELECTRICAL | Value | Unit | Standard |
| Hot Wire Ignition {PLC) | 3 | PLC Code | UL 746A |
| High Ampere Arc Ign, surface {PLC} | 0 | PLC Code | UL 746A |
| Comparative Tracking Index (UL) {PLC} | 1 | PLC Code | UL 746A |
| FLAME CHARACTERISTICS | Value | Unit | Standard |
| UL Recognized, 94V-0 Flame Class Rating (3) | 1.49 | mm | UL 94 |
| UL Recognized, 94-5VB Rating (3) | 2.48 | mm | UL 94 |
| Source GMD, last updated:01/31/2001 | |||
| Parameter | |||
| Injection Molding | Value | Unit | |
| Drying Temperature | 75 - 80 | °C | |
| Drying Time | 3 - 4 | hrs | |
| Drying Time (Cumulative) | 8 | hrs | |
| Maximum Moisture Content | 0.04 | % | |
| Melt Temperature | 230 - 275 | °C | |
| Nozzle Temperature | 230 - 275 | °C | |
| Front - Zone 3 Temperature | 225 - 275 | °C | |
| Middle - Zone 2 Temperature | 215 - 260 | °C | |
| Rear - Zone 1 Temperature | 210 - 255 | °C | |
| Mold Temperature | 50 - 70 | °C | |
| Back Pressure | 0.3 - 0.7 | MPa | |
| Screw Speed | 40 - 70 | rpm | |
| Shot to Cylinder Size | 30 - 80 | % | |
| Vent Depth | 0.038 - 0.076 | mm | |
| Source GMD, last updated:01/31/2001 | |||
