S-Plastics Thermocomp WX02869H resin is a compound based on Polyester, TP resin containing High Specific Gravity. Added features of thismaterial include: High Impact.
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield | 26 | MPa | ASTM D 638 |
| Tensile Stress, break | 24 | MPa | ASTM D 638 |
| Tensile Strain, yield | 13 | % | ASTM D 638 |
| Tensile Strain, break | 23.8 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 1820 | MPa | ASTM D 638 |
| Flexural Stress | 48 | MPa | ASTM D 790 |
| Flexural Modulus | 2030 | MPa | ASTM D 790 |
| Tensile Stress, yield | 27 | MPa | ISO 527 |
| Tensile Stress, break | 27 | MPa | ISO 527 |
| Tensile Strain, yield | 9.4 | % | ISO 527 |
| Tensile Strain, break | 11.1 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 1780 | MPa | ISO 527 |
| Flexural Stress | 42 | MPa | ISO 178 |
| Flexural Modulus | 1930 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 1372 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 101 | J/m | ASTM D 256 |
| Instrumented Impact Energy @ peak, 23°C | 9 | J | ASTM D 3763 |
| Multiaxial Impact | 14 | J | ISO 6603 |
| Izod Impact, unnotched 80*10*4 +23°C | 84 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 10 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 3.2mm, unannealed | 66 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, flow | 9.25E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, xflow | 9.17E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, flow | 9.25E-05 | 1/°C | ISO 11359-2 |
| CTE, -40°C to 40°C, xflow | 9.18E-05 | 1/°C | ISO 11359-2 |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 57 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 4.86 | g/cm³ | ASTM D 792 |
| Moisture Absorption, 50% RH, 24 hrs | 0.04 | % | ASTM D 570 |
| Mold Shrinkage, flow, 24 hrs | 1.3 | % | ASTM D 955 |
| Mold Shrinkage, xflow, 24 hrs | 1.1 | % | ASTM D 955 |
| Mold Shrinkage, flow, 24 hrs | 1.3 | % | ISO 294 |
| Mold Shrinkage, xflow, 24 hrs | 1.11 | % | ISO 294 |
| Density | 4.87 | g/cm³ | ISO 1183 |
| Moisture Absorption (23°C / 50% RH) | 0.06 | % | ISO 62 |
| Source GMD, last updated:10/02/2004 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 120 | °C |
| Drying Time | 4 | hrs |
| Maximum Moisture Content | 0.05 | % |
| Melt Temperature | 240 - 265 | °C |
| Front - Zone 3 Temperature | 260 - 270 | °C |
| Middle - Zone 2 Temperature | 245 - 255 | °C |
| Rear - Zone 1 Temperature | 220 - 230 | °C |
| Mold Temperature | 80 - 100 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 30 - 60 | rpm |
| Source GMD, last updated:10/02/2004 | ||
