S-Plastics Thermocomp Lexan_SP7602 resin is ……………………
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield | 82 | MPa | S-Plastics - Japan Method |
| Tensile Strain, break | 10 - 20 | % | S-Plastics - Japan Method |
| Flexural Stress | 120 | MPa | ASTM D 790 |
| Flexural Modulus | 3920 | MPa | ASTM D 790 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 88 | J/m | ASTM D 256 |
| THERMAL | Value | Unit | Standard |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 100 | °C | ASTM D 648 |
| CTE, -30°C to 30°C | 4.E-05 - 6.E-05 | 1/°C | TMA |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.28 | - | ASTM D 792 |
| Water Absorption, 24 hours | 0.12 | % | ASTM D 570 |
| Mold Shrinkage, flow, 3.2 mm | 0.3 - 0.4 | % | S-Plastics Method |
| ELECTRICAL | Value | Unit | Standard |
| Surface Resistivity | 1.E+16 | Ohm | ASTM D 257 |
| FLAME CHARACTERISTICS | Value | Unit | Standard |
| UL Recognized, 94V-0 Flame Class Rating (3) | 0.75 | mm | UL 94 |
| Source GMD, last updated:2005/11/02 | |||
