| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, brk, Type I, 5 mm/min | 124 | MPa | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 4.5 | % | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 195 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 15160 | MPa | ASTM D 790 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 453 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 69 | J/m | ASTM D 256 |
| Izod Impact, Reverse Notched, 3.2 mm | 352 | J/m | ASTM D 256 |
| Instrumented Impact Total Energy, 23°C | 12 | J | ASTM D 3763 |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 6.4 mm, unannealed | 137 | °C | ASTM D 648 |
| ELECTRICAL | Value | Unit | Standard |
| Volume Resistivity | 7.5E+01 | Ohm-cm | ASTM D 257 |
| Surface Resistivity | 5.E+03 | Ohm | ASTM D 257 |
| Static Decay, 5000V to <50V | 0.01 | < seconds | FTMS101B |
| Source GMD, last updated:02/18/1999 | |||
Processing
| Parameter | |||
| Injection Molding | Value | Unit | |
| Drying Temperature | 120 | °C | |
| Drying Time | 3 - 4 | hrs | |
| Drying Time (Cumulative) | 10 | hrs | |
| Maximum Moisture Content | 0.02 | % | |
| Melt Temperature | 275 - 300 | °C | |
| Nozzle Temperature | 270 - 295 | °C | |
| Front - Zone 3 Temperature | 275 - 300 | °C | |
| Middle - Zone 2 Temperature | 265 - 290 | °C | |
| Rear - Zone 1 Temperature | 255 - 275 | °C | |
| Mold Temperature | 70 - 95 | °C | |
| Back Pressure | 0.3 - 0.7 | MPa | |
| Screw Speed | 40 - 70 | rpm | |
| Shot to Cylinder Size | 40 - 60 | % | |
| Vent Depth | 0.025 - 0.076 | mm | |
| Source GMD, last updated:02/18/1999 | |||
