S-Plastics Valox VX5011 resin is a 10% glass fibre reinforced PBT+PC blend with low warpage characteristics
| Taber Abrasion, CS-17, 1 kg | 54 | mg/1000cy | S-Plastics Method | |
| Tensile Stress, break, 5 mm/min | 85 | MPa | ISO 527 | |
| Tensile Strain, break, 5 mm/min | 3.2 | % | ISO 527 | |
| Tensile Modulus, 1 mm/min | 4500 | MPa | ISO 527 | |
| Flexural Stress, break, 2 mm/min | 130 | MPa | ISO 178 | |
| Flexural Modulus, 2 mm/min | 3900 | MPa | ISO 178 | |
| Hardness, H358/30 | 130 | MPa | ISO 2039-1 | |
| Hardness, Rockwell R | 122 | - | ISO 2039-2 | |
| IMPACT | Value | Unit | Standard | |
| Izod Impact, unnotched 80*10*4 +23°C | 40 | kJ/m² | ISO 180/1U | |
| Izod Impact, unnotched 80*10*4 -30°C | 30 | kJ/m² | ISO 180/1U | |
| Izod Impact, notched 80*10*4 +23°C | 4 | kJ/m² | ISO 180/1A | |
| Izod Impact, notched 80*10*4 -30°C | 4 | kJ/m² | ISO 180/1A | |
| Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm | 4 | kJ/m² | ISO 179/1eA | |
| Charpy -30°C, V-notch Edgew 80*10*4 sp=62mm | 4 | kJ/m² | ISO 179/1eA | |
| Charpy 23°C, Unnotch Edgew 80*10*4 sp=62mm | 40 | kJ/m² | ISO 179/1eU | |
| Charpy -30°C, Unnotch Edgew 80*10*4 sp=62mm | 30 | kJ/m² | ISO 179/1eU | |
| THERMAL | Value | Unit | Standard | |
| CTE, 23°C to 80°C, flow | 4.E-05 | 1/°C | ISO 11359-2 | |
| CTE, 23°C to 80°C, xflow | 9.E-05 | 1/°C | ISO 11359-2 | |
| Ball Pressure Test, 125°C +/- 2°C | PASSES | - | IEC 60695-10-2 | |
| Vicat Softening Temp, Rate A/50 | 200 | °C | ISO 306 | |
| Vicat Softening Temp, Rate B/50 | 140 | °C | ISO 306 | |
| Vicat Softening Temp, Rate B/120 | 143 | °C | ISO 306 | |
| HDT/Be, 0.45MPa Edgew 120*10*4 sp=100mm | 135 | °C | ISO 75/Be | |
| HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm | 95 | °C | ISO 75/Ae | |
| PHYSICAL | Value | Unit | Standard | |
| Mold Shrinkage on Tensile Bar, flow (2) | 0.3 - 0.8 | % | S-Plastics Method | |
| Mold Shrinkage on Tensile Bar, xflow (2) | 0.5 - 0.9 | % | S-Plastics Method | |
| Density | 1.31 | g/cm³ | ISO 1183 | |
| Water Absorption, (23°C/sat) | 0.15 | % | ISO 62 | |
| Moisture Absorption (23°C / 50% RH) | 0.1 | % | ISO 62 | |
| Melt Volume Rate, MVR at 250°C/2.16 kg | 18 | cm³/10 min | ISO 1133 | |
| ELECTRICAL | Value | Unit | Standard | |
| Volume Resistivity | >1.E+15 | Ohm-cm | IEC 60093 | |
| Surface Resistivity, ROA | >1.E+15 | Ohm | IEC 60093 | |
| Dielectric Strength, in oil, 0.8 mm | 29 | kV/mm | IEC 60243-1 | |
| Dielectric Strength, in oil, 1.6 mm | 24 | kV/mm | IEC 60243-1 | |
| Dielectric Strength, in oil, 3.2 mm | 14 | kV/mm | IEC 60243-1 | |
| Relative Permittivity, 50/60 Hz | 3 | - | IEC 60250 | |
| Relative Permittivity, 100 Hz | 3.2 | - | IEC 60250 | |
| Relative Permittivity, 1 MHz | 2.9 | - | IEC 60250 | |
| Dissipation Factor, 50/60 Hz | 0.009 | - | IEC 60250 | |
| Dissipation Factor, 100 Hz | 0.016 | - | IEC 60250 | |
| Dissipation Factor, 1 MHz | 0.004 | - | IEC 60250 | |
| Comparative Tracking Index | 200 | V | IEC 60112 | |
| Comparative Tracking Index, M | 100 | V | IEC 60112 | |
| FLAME CHARACTERISTICS | Value | Unit | Standard | |
| UL Compliant, 94HB Flame Class Rating (3)(4) | 1.6 | mm | UL 94 by GE | |
| Glow Wire Flammability Index 750°C, passes at | 1 | mm | IEC 60695-2-12 | |
| Glow Wire Flammability Index 850°C, passes at | 3 | mm | IEC 60695-2-12 | |
| Oxygen Index (LOI) | 21 | % | ISO 4589 | |
| Source GMD, last updated:12/22/1998 | ||||
| Injection Molding | Value | Unit |
| Drying Temperature | 110 - 120 | °C |
| Drying Time | 2 - 4 | hrs |
| Maximum Moisture Content | 0.02 | % |
| Melt Temperature | 250 - 270 | °C |
| Nozzle Temperature | 240 - 260 | °C |
| Front - Zone 3 Temperature | 245 - 265 | °C |
| Middle - Zone 2 Temperature | 240 - 255 | °C |
| Rear - Zone 1 Temperature | 230 - 245 | °C |
| Hopper Temperature | 40 - 60 | °C |
| Mold Temperature | 40 - 100 | °C |
| Source GMD, last updated:12/22/1998 | ||
