S-Plastics Valox EXVX0134resin is Valox iQ* resin made with environmentally sustainable, low carbon footprint iQ-PBT resin, 15% GF, and 50% higher flow than a typicalPBT GF15. This grade also meets USCAR (United States Council for Automotive Research) Class 2 requirements for unsealedconnectors.
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 100 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 5 mm/min | 100 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 5 mm/min | 2.9 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 2.9 | % | ASTM D 638 |
| Tensile Modulus, 5 mm/min | 6360 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 164 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 5470 | MPa | ASTM D 790 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 48 | J/m | ASTM D 256 |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 3.2mm, unannealed | 195 | °C | ASTM D 648 |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.42 | - | ASTM D 792 |
| Melt Volume Rate, MVR at 260°C/2.16 kg | 18 | cm³/10 min | ISO 1133 |
| Source GMD, last updated:10/07/2008 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 110 | °C |
| Drying Time | 2 - 3 | hrs |
| Drying Time (Cumulative) | 12 | hrs |
| Maximum Moisture Content | 0.02 | % |
| Melt Temperature | 240 - 255 | °C |
| Nozzle Temperature | 235 - 250 | °C |
| Front - Zone 3 Temperature | 240 - 255 | °C |
| Middle - Zone 2 Temperature | 235 - 250 | °C |
| Rear - Zone 1 Temperature | 225 - 245 | °C |
| Mold Temperature | 50 - 80 | °C |
| Back Pressure | 0.3 - 0.7 | MPa |
| Screw Speed | 50 - 80 | rpm |
| Shot to Cylinder Size | 40 - 80 | % |
| Vent Depth | 0.025 - 0.038 | mm |
| Source GMD, last updated:10/07/2008 | ||
|
For more information please download the datasheet |
|
 |
S-Plastics Valox EXVX0134.pdf |
|
