S-Plastics Cycolac 29449 resin is a low gloss bulk ABS injection moulding grade for multipurpose applications.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yield, 50 mm/min | 32 | MPa | ISO 527 |
| Tensile Stress, break, 50 mm/min | 25 | MPa | ISO 527 |
| Tensile Strain, yield, 50 mm/min | 2.3 | % | ISO 527 |
| Tensile Strain, break, 50 mm/min | 45 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 1750 | MPa | ISO 527 |
| Flexural Stress, yield, 2 mm/min | 50 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 1750 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched 80*10*4 +23°C | 21 | kJ/m² | ISO 180/1A |
| Izod Impact, notched 80*10*4 -30°C | 8 | kJ/m² | ISO 180/1A |
| Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm | 18 | kJ/m² | ISO 179/1eA |
| Charpy -30°C, V-notch Edgew 80*10*4 sp=62mm | 8 | kJ/m² | ISO 179/1eA |
| THERMAL | Value | Unit | Standard |
| Vicat Softening Temp, Rate B/50 | 88 | °C | ISO 306 |
| Vicat Softening Temp, Rate B/120 | 90 | °C | ISO 306 |
| HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm | 75 | °C | ISO 75/Ae |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.05 | g/cm³ | ISO 1183 |
| Water Absorption, (23°C/sat) | 1 | % | ISO 62 |
| Moisture Absorption (23°C / 50% RH) | 0.2 | % | ISO 62 |
| Melt Volume Rate, MVR at 220°C/10.0 kg | 18 | cm³/10 min | ISO 1133 |
| FLAME CHARACTERISTICS | Value | Unit | Standard |
| FMVSS Burning Speed, thickness 1 mm | 35 | mm/min | FMVSS 302 |
| Source GMD, last updated:08/13/2002 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 85 - 95 | °C |
| Drying Time | 2 - 4 | hrs |
| Maximum Moisture Content | 0.1 | % |
| Melt Temperature | 230 - 275 | °C |
| Nozzle Temperature | 230 - 275 | °C |
| Front - Zone 3 Temperature | 220 - 255 | °C |
| Middle - Zone 2 Temperature | 210 - 250 | °C |
| Rear - Zone 1 Temperature | 190 - 240 | °C |
| Hopper Temperature | 60 - 80 | °C |
| Mold Temperature | 50 - 80 | °C |
| Source GMD, last updated:08/13/2002 | ||
