S-Plastics Lubricomp RFI12 resin is LNP* RFI12 is a compound based on Nylon 6/6 resin containing glass fibers and silicone fillers.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 114 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 5 mm/min | 114 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 5 mm/min | 2.8 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 2.8 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 5500 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 166 | MPa | ASTM D 790 |
| Flexural Stress, brk, 1.3 mm/min, 50 mm span | 165 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 4780 | MPa | ASTM D 790 |
| Tensile Stress, yield, 5 mm/min | 107 | MPa | ISO 527 |
| Tensile Stress, break, 5 mm/min | 107 | MPa | ISO 527 |
| Tensile Strain, yield, 5 mm/min | 2.6 | % | ISO 527 |
| Tensile Strain, break, 5 mm/min | 2.6 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 5260 | MPa | ISO 527 |
| Flexural Stress | 155 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 4430 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 462 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 40 | J/m | ASTM D 256 |
| Multiaxial Impact | 1 | J | ISO 6603 |
| Instrumented Impact Total Energy, 23°C | 5 | J | ASTM D 3763 |
| Izod Impact, unnotched 80*10*4 +23°C | 27 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 4 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 257 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 3.2mm, unannealed | 241 | °C | ASTM D 648 |
| HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm | 255 | °C | ISO 75/Bf |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 236 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.25 | - | ASTM D 792 |
| Density | 1.25 | g/cm³ | ASTM D 792 |
| Moisture Absorption, 50% RH, 24 hrs | 0.98 | % | ASTM D 570 |
| Mold Shrinkage, flow, 24 hrs | 0.9 - 2 | % | ASTM D 955 |
| Mold Shrinkage, xflow, 24 hrs | 1 - 3 | % | ASTM D 955 |
| Wear Factor Washer | 260 | 10^-10 in^5-min/ft-lb-hr | ASTM D 3702 Modified |
| Dynamic COF | 0.47 | - | ASTM D 3702 Modified |
| Static COF | 0.43 | - | ASTM D 3702 Modified |
| Moisture Absorption (23°C / 50% RH) | 1.5 | % | ISO 62 |
| Source GMD, last updated:05/20/2008 | |||
