S-Plastics Verton NV004E resin is a compound based on PC+ABS Blend resin containing Long Glass. Added features of this material include:
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, break | 119 | MPa | ASTM D 638 |
| Tensile Strain, break | 2.4 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 6610 | MPa | ASTM D 638 |
| Flexural Stress | 159 | MPa | ASTM D 790 |
| Flexural Modulus | 5670 | MPa | ASTM D 790 |
| Tensile Stress, break | 124 | MPa | ISO 527 |
| Tensile Strain, break | 2.1 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 7790 | MPa | ISO 527 |
| Flexural Stress | 139 | MPa | ISO 178 |
| Flexural Modulus | 6970 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 571 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 161 | J/m | ASTM D 256 |
| Izod Impact, notched, -40°C | 166 | J/m | ASTM D 256 |
| Instrumented Impact Energy @ peak, 23°C | 16 | J | ASTM D 3763 |
| Izod Impact, unnotched 80*10*4 +23°C | 41 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 18 | kJ/m² | ISO 180/1A |
| Izod Impact, notched 80*10*4 -40°C | 17 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 3.2mm, unannealed | 133 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, flow | 4.32E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, xflow | 4.68E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, flow | 4.45E-05 | 1/°C | ISO 11359-2 |
| CTE, -40°C to 40°C, xflow | 4.77E-05 | 1/°C | ISO 11359-2 |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.3 | g/cm³ | ASTM D 792 |
| Mold Shrinkage, flow, 24 hrs | 0.2 - 0.4 | % | ASTM D 955 |
| Mold Shrinkage, xflow, 24 hrs | 0.2 - 0.4 | % | ASTM D 955 |
| Mold Shrinkage, flow, 24 hrs | 0.2 - 0.4 | % | ISO 294 |
| Mold Shrinkage, xflow, 24 hrs | 0.2 - 0.4 | % | ISO 294 |
| Density | 1.3 | g/cm³ | ISO 1183 |
| Moisture Absorption (23°C / 50% RH) | 0.1 | % | ISO 62 |
| Source GMD, last updated:10/02/2004 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 80 - 95 | °C |
| Drying Time | 2 - 4 | hrs |
| Maximum Moisture Content | 0.04 | % |
| Melt Temperature | 275 - 290 | °C |
| Front - Zone 3 Temperature | 280 - 295 | °C |
| Middle - Zone 2 Temperature | 270 - 280 | °C |
| Rear - Zone 1 Temperature | 260 - 270 | °C |
| Mold Temperature | 60 - 95 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 30 - 60 | rpm |
| Source GMD, last updated:10/02/2004 | ||
