S-Plastic Verton RV00CE is a compound based on Nylon 66 resin containing Long Glass. Added features of this material includ

100KG
MOQ
*USD
Price
S-Plastic Verton RV00CE is a compound based on Nylon 66 resin containing Long Glass. Added features of this material includ
Features Gallery Product Description Request A Quote
Features
Specifications
Melt Volume Rate, MVR At 260°C/2.16 Kg: ???
UL Recognized, 94HB Flame Class Rating (3): ???
Basic Infomation
Place of Origin: ——
Brand Name: S-Plastic Verton
Certification: Datasheet,MSDS,ROHS,SGS,REACH,FDA,EU,UL,COC/COA ,please contact us
Model Number: RV00CE
Payment & Shipping Terms
Packaging Details: 25KG/bag
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

S-Plastics Verton RV00CE resin is a compound based on Nylon 66 resin containing Long Glass. Added features of this material include: Easy


Property

TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, break 261 MPa ISO 527
Tensile Strain, break 1.6 % ISO 527
Tensile Modulus, 1 mm/min 23280 MPa ISO 527
Flexural Stress 433 MPa ISO 178
Flexural Modulus 18920 MPa ISO 178
IMPACT Value Unit Standard
Izod Impact, unnotched 80*10*4 +23°C 102 kJ/m² ISO 180/1U
Izod Impact, notched 80*10*4 +23°C 54 kJ/m² ISO 180/1A
Izod Impact, notched 80*10*4 -40°C 43 kJ/m² ISO 180/1A
THERMAL Value Unit Standard
CTE, -40°C to 40°C, flow 1.7E-05 1/°C ISO 11359-2
CTE, -40°C to 40°C, xflow 5.3E-05 1/°C ISO 11359-2
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm 252 °C ISO 75/Af
PHYSICAL Value Unit Standard
Mold Shrinkage, flow, 24 hrs 0.2 % ISO 294
Mold Shrinkage, xflow, 24 hrs 0.41 % ISO 294
Density 1.71 g/cm³ ISO 1183
Source GMD, last updated:10/02/2004

Processing

Parameter
Injection Molding Value Unit
Drying Temperature 80 °C
Drying Time 4 hrs
Maximum Moisture Content 0.15 - 0.25 %
Melt Temperature 290 - 305 °C
Front - Zone 3 Temperature 290 - 300 °C
Middle - Zone 2 Temperature 290 - 300 °C
Rear - Zone 1 Temperature 280 - 295 °C
Mold Temperature 95 - 110 °C
Back Pressure 0.2 - 0.3 MPa
Screw Speed 30 - 60 rpm
Source GMD, last updated:10/02/2004






Other related products we recommend:

For more information please download the datasheet

S-Plastic Verton RV00CE is a compound based on Nylon 66 resin containing Long Glass. Added features of this material includ 0  S-Plastics Verton RV00CE.pdf
