S-Plastics Lubricomp Ultem_UCF1205 resin is
Property
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 133 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 5 mm/min | 133 | MPa | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 5.3 | % | ASTM D 638 |
| Tensile Modulus, 5 mm/min | 8960 | MPa | ASTM D 638 |
| Flexural Stress, brk, 1.3 mm/min, 50 mm span | 186 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 8130 | MPa | ASTM D 790 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 395 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 58 | J/m | ASTM D 256 |
| Instrumented Impact Total Energy, 23°C | 11 | J | ASTM D 3763 |
| THERMAL | Value | Unit | Standard |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 215 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 3.2mm, unannealed | 210 | °C | ASTM D 648 |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.35 | - | ASTM D 792 |
| ELECTRICAL | Value | Unit | Standard |
| Volume Resistivity | 1.E+03 | Ohm-cm | ASTM D 257 |
| Surface Resistivity | 1.E+05 | Ohm | ASTM D 257 |
| Source GMD, last updated:08/02/2000 | |||
Processing
| Parameter | |||
| Injection Molding | Value | Unit | |
| Drying Temperature | 150 | °C | |
| Drying Time | 4 - 6 | hrs | |
| Drying Time (Cumulative) | 24 | hrs | |
| Maximum Moisture Content | 0.02 | % | |
| Melt Temperature | 380 - 425 | °C | |
| Nozzle Temperature | 375 - 420 | °C | |
| Front - Zone 3 Temperature | 380 - 425 | °C | |
| Middle - Zone 2 Temperature | 370 - 420 | °C | |
| Rear - Zone 1 Temperature | 360 - 405 | °C | |
| Mold Temperature | 135 - 165 | °C | |
| Back Pressure | 0.3 - 0.7 | MPa | |
| Screw Speed | 40 - 70 | rpm | |
| Shot to Cylinder Size | 40 - 60 | % | |
| Vent Depth | 0.025 - 0.076 | mm | |
| Source GMD, last updated:08/02/2000 | |||
