ZX89743 S-Plastic Lubricomp PPE PS Resin Material Plastic Containing Glass Fiber

100KG
MOQ
*USD
Price
ZX89743 S-Plastic Lubricomp PPE PS Resin Material Plastic Containing Glass Fiber
Features Gallery Product Description Request A Quote
Features
Specifications
Density: 1.34
Mold Shrinkage, Flow: 0.36
Highlight:

S-Plastic Lubricomp Resin Material

,

S-Plastic Lubricomp ZX89743

,

Lubricomp resin material plastic

Basic Infomation
Place of Origin: ——
Brand Name: S-Plastic Lubricomp
Certification: COA/ICP Test/Rohs/MSDS
Model Number: ZX89743
Payment & Shipping Terms
Packaging Details: 25KG/bag
Delivery Time: To be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: To be negotiated
Product Description

S-Plastics Lubricomp ZX89743 resin is a compound based on PPE+PS Blend resin containing Glass Fiber, Glass Beads and a Proprietary

Lubricant. Added features include : Internally Lubricated.





Property


TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Tensile Stress, break, 5 mm/min 74 MPa ISO 527
Tensile Strain, break, 5 mm/min 2.3 % ISO 527
Tensile Modulus, 1 mm/min 5300 MPa ISO 527
Flexural Stress, yield, 2 mm/min 108 MPa ISO 178
IMPACT Value Unit Standard
Izod Impact, unnotched 80*10*4 +23°C 20 kJ/m² ISO 180/1U
Izod Impact, notched 80*10*4 +23°C 6 kJ/m² ISO 180/1A
THERMAL Value Unit Standard
HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm 135 °C ISO 75/Bf
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm 126 °C ISO 75/Af
PHYSICAL Value Unit Standard
Mold Shrinkage, flow 0.36 % S-Plastics Method
Density 1.34 g/cm³ ISO 1183
FLAME CHARACTERISTICS Value Unit Standard
UL Recognized, 94V-1 Flame Class Rating (3) 1.6 mm UL 94
Source GMD, last updated:11/26/2007


Processing


Parameter
Injection Molding Value Unit
Drying Temperature 120 °C
Drying Time 4 hrs
Melt Temperature 300 - 305 °C
Front - Zone 3 Temperature 300 - 310 °C
Middle - Zone 2 Temperature 290 - 300 °C
Rear - Zone 1 Temperature 275 - 290 °C
Mold Temperature 80 - 110 °C
Back Pressure 0.2 - 0.3 MPa
Screw Speed 30 - 60 rpm
Source GMD, last updated:11/26/2007



Our customers

In recent years, we have deeply cultivated the domestic market and actively explored foreign markets.Up to now, we have provided high-quality products and services to more than 1,000 customers in various industries, including: electronics and electrical appliances, medical, food, automotive electronics, optoelectronic communications, photovoltaic new energy, water treatment, transportation and other industries.

Samtion chemical supplies engineering plastics and special modified materials of S-Plastics and other brands.Our authentic products are guaranteed, with complete qualifications and superior supply capacity and price advantages.
Every batch of our products is subject to strict quality inspection to ensure the original supply. All products have MSDS, ROHS, SGS, REACH, FDA, EU, UL, COC / COA certificates!!





For more information please download the datesheet

ZX89743 S-Plastic Lubricomp PPE PS Resin Material Plastic Containing Glass Fiber 0  S-Plastics Lubricomp ZX89743.pdf
