S-Plastics Ultem HFATX resin is High flow Polyimide blend with internal mold release. ECO Conforming.
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, yld, Type I, 5 mm/min | 92 | MPa | ASTM D 638 |
| Tensile Stress, brk, Type I, 5 mm/min | 82 | MPa | ASTM D 638 |
| Tensile Strain, yld, Type I, 5 mm/min | 7 | % | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 20 | % | ASTM D 638 |
| Tensile Modulus, 5 mm/min | 2900 | MPa | ASTM D 638 |
| Flexural Stress, yld, 1.3 mm/min, 50 mm span | 146 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 3200 | MPa | ASTM D 790 |
| Tensile Stress, yield, 5 mm/min | 95 | MPa | ISO 527 |
| Tensile Stress, break, 5 mm/min | 84 | MPa | ISO 527 |
| Tensile Strain, yield, 5 mm/min | 6.7 | % | ISO 527 |
| Tensile Strain, break, 5 mm/min | 27 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 3080 | MPa | ISO 527 |
| Flexural Stress, yield, 2 mm/min | 138 | MPa | ISO 178 |
| Flexural Modulus, 2 mm/min | 2950 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, notched, 23°C | 48 | J/m | ASTM D 256 |
| Izod Impact, notched, -30°C | 45 | J/m | ASTM D 256 |
| Izod Impact, Reverse Notched, 3.2 mm | 1500 | J/m | ASTM D 256 |
| Instrumented Impact Total Energy, 23°C | 35 | J | ASTM D 3763 |
| Izod Impact, unnotched 80*10*4 +23°C | 131 | kJ/m² | ISO 180/1U |
| Izod Impact, unnotched 80*10*4 -30°C | 125 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 4 | kJ/m² | ISO 180/1A |
| Izod Impact, notched 80*10*4 -30°C | 5 | kJ/m² | ISO 180/1A |
| Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm | 6 | kJ/m² | ISO 179/1eA |
| Charpy -30°C, V-notch Edgew 80*10*4 sp=62mm | 5 | kJ/m² | ISO 179/1eA |
| Charpy 23°C, Unnotch Edgew 80*10*4 sp=62mm | 180 | kJ/m² | ISO 179/1eU |
| Charpy -30°C, Unnotch Edgew 80*10*4 sp=62mm | 115 | kJ/m² | ISO 179/1eU |
| THERMAL | Value | Unit | Standard |
| Vicat Softening Temp, Rate B/50 | 201 | °C | ASTM D 1525 |
| HDT, 0.45 MPa, 3.2 mm, unannealed | 199 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 3.2mm, unannealed | 180 | °C | ASTM D 648 |
| HDT, 1.82 MPa, 6.4 mm, unannealed | 186 | °C | ASTM D 648 |
| CTE, -40°C to 150°C, flow | 5.3E-05 | 1/°C | ASTM E 831 |
| CTE, -40°C to 150°C, xflow | 5.3E-05 | 1/°C | ASTM E 831 |
| CTE, 23°C to 150°C, flow | 5.3E-05 | 1/°C | ISO 11359-2 |
| CTE, 23°C to 150°C, xflow | 5.3E-05 | 1/°C | ISO 11359-2 |
| Ball Pressure Test, 125°C +/- 2°C | Passes | - | IEC 60695-10-2 |
| Vicat Softening Temp, Rate B/50 | 192 | °C | ISO 306 |
| Vicat Softening Temp, Rate B/120 | 201 | °C | ISO 306 |
| HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm | 175 | °C | ISO 75/Ae |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.25 | - | ASTM D 792 |
| Mold Shrinkage on Tensile Bar, flow (2) | 0.6 - 0.8 | % | S-Plastics Method |
| Mold Shrinkage, flow, 3.2 mm | 0.6 - 0.8 | % | S-Plastics Method |
| Mold Shrinkage, xflow, 3.2 mm | 0.6 - 0.8 | % | S-Plastics Method |
| Melt Flow Rate, 295°C/6.6 kgf | 8 | g/10 min | ASTM D 1238 |
| Melt Flow Rate, 337°C/6.6 kgf | 66 | g/10 min | ASTM D 1238 |
| Density | 1.25 | g/cm³ | ISO 1183 |
| Water Absorption, (23°C/sat) | 0.9 | % | ISO 62 |
| Moisture Absorption (23°C / 50% RH) | 0.5 | % | ISO 62 |
| Melt Volume Rate, MVR at 340°C/5.0 kg | 40 | cm³/10 min | ISO 1133 |
| Source GMD, last updated:02/09/2004 | |||
| Injection Molding | Value | Unit |
| Drying Temperature | 140 | °C |
| Drying Time | 4 - 6 | hrs |
| Drying Time (Cumulative) | 12 | hrs |
| Maximum Moisture Content | 0.02 | % |
| Melt Temperature | 330 - 370 | °C |
| Nozzle Temperature | 330 - 370 | °C |
| Front - Zone 3 Temperature | 330 - 370 | °C |
| Middle - Zone 2 Temperature | 325 - 365 | °C |
| Rear - Zone 1 Temperature | 320 - 360 | °C |
| Mold Temperature | 120 - 150 | °C |
| Back Pressure | 0.3 - 0.7 | MPa |
| Screw Speed | 40 - 70 | rpm |
| Shot to Cylinder Size | 40 - 60 | % |
| Vent Depth | 0.025 - 0.076 | mm |
| Source GMD, last updated:02/09/2004 | ||
|
