S-Plastics Stat-kon EX08318C resin is a polyimide compound reinforced with carbon fiber for good stiffness, dimension stability and has
extremely high level of cleanliness for the most demanding application. A unique feature of this material is its low non-volatile residue
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, brk, Type I, 5 mm/min | 210 | MPa | ASTM D 638 |
| Tensile Strain, brk, Type I, 5 mm/min | 1.8 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 22680 | MPa | ASTM D 638 |
| Flexural Stress, brk, 1.3 mm/min, 50 mm span | 268 | MPa | ASTM D 790 |
| Flexural Modulus, 1.3 mm/min, 50 mm span | 18200 | MPa | ASTM D 790 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 348 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 46 | J/m | ASTM D 256 |
| THERMAL | Value | Unit | Standard |
| HDT, 1.82 MPa, 6.4 mm, unannealed | 202 | °C | ASTM D 648 |
| CTE, -40°C to 40°C, flow | 4.9E-06 | 1/°C | ASTM E 831 |
| CTE, -40°C to 40°C, xflow | 4.4E-05 | 1/°C | ASTM E 831 |
| PHYSICAL | Value | Unit | Standard |
| Density | 1.388 | g/cm³ | ASTM D 792 |
| Moisture Absorption, 50% RH, 24 hrs | 0.2 | % | ASTM D 570 |
| Mold Shrinkage, flow, 24 hrs | 0.25 - 0.31 | % | ASTM D 955 |
| Mold Shrinkage, xflow, 24 hrs | 0.38 - 0.45 | % | ASTM D 955 |
| ELECTRICAL | Value | Unit | Standard |
| Volume Resistivity | 5.E+03 - 5.E+06 | Ohm-cm | ASTM D 257 |
| Surface Resistivity | 5.E+03 - 5.E+05 | Ohm | ASTM D 257 |
| Static Decay, 5000V to <50V | 0.1 | < seconds | FTMS101B |
| Source GMD, last updated:2009/02/11 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 150 | °C |
| Drying Time | 4 - 6 | hrs |
| Drying Time (Cumulative) | 24 | hrs |
| Maximum Moisture Content | 0.02 | % |
| Melt Temperature | 350 - 380 | °C |
| Nozzle Temperature | 345 - 380 | °C |
| Front - Zone 3 Temperature | 345 - 380 | °C |
| Middle - Zone 2 Temperature | 340 - 380 | °C |
| Rear - Zone 1 Temperature | 330 - 380 | °C |
| Mold Temperature | 135 - 165 | °C |
| Back Pressure | 0.3 - 0.7 | MPa |
| Screw Speed | 40 - 70 | rpm |
| Shot to Cylinder Size | 40 - 60 | % |
| Vent Depth | 0.025 - 0.076 | mm |
| Source GMD, last updated:2009/02/11 | ||
