S-Plastics Geloy INP272 resin is a 45% polybutyl acrylate large (500 nm) rubber grafted extra-weatherable ASA modifier resin.Provides excellent impact, heat distortion and weatherability properties.Maintains polymer properties in UV and thermal environments.Toughens compatible rigid
polymers without additional impact modification.Expands the use temperature window of compounds.Offers compatibility with many polar
polymers.Improve UV resistance when blended with less stable polymers.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Hardness, Shore D | 60 | - | ASTM D 2240 |
| PHYSICAL | Value | Unit | Standard |
| Specific Gravity | 1.07 | - | ASTM D 792 |
| Density (Molded) | 1.07 | g/cm³ | ISO 1183 |
| Mean Resin Particle Size | 360 | micrometer | S-Plastics Method |
| Total NA Volatiles | 0.1 | % | S-Plastics Method |
| Rubber | 45 | % | S-Plastics Method |
| Source GMD, last updated:2010/02/25 |
| THESE PROPERTY VALUES ARE NOT INTENDED FOR SPECIFICATION PURPOSES. | |||
| PLEASE CHECK WITH YOUR (LOCAL SALES OFFICE) FOR AVAILABILITY IN YOUR REGION | |||
| (1) Typical values only. Variations within normal tolerances are possible for various colors. All values are measured after at least 48 hours storage at 23°C/50% relative humidity. All properties, except the melt volume and melt flow rates, are measured on injection molded samples. All samples tested under ISO test standards are prepared according to ISO 294. |
|||
| (2) Only typical data for selection purposes. Not to be used for part or tool design. | |||
| (3) This rating is not intended to reflect hazards presented by this or any other material under actual fire conditions. | |||
| (4) Internal measurements according to UL standards. | |||
| (5) Measurements made from laboratory test coupon. Actual shrinkage may vary outside of range due to differences in processing conditions, equipment, part geometry and tool design. It is recommended that mold shrinkage studies be performed with surrogate or legacy tooling prior to cutting tools for new molded article. |
|||
