S-Plastics Verton OTF2B resin is a compound based on PPS - Linear resin containing Glass Fiber, Proprietary Thermal Filler. Added features of
this material include: Thermally Conductive.
| TYPICAL PROPERTIES (1) | |||
| MECHANICAL | Value | Unit | Standard |
| Tensile Stress, break | 83 | MPa | ASTM D 638 |
| Tensile Strain, break | 0.9 | % | ASTM D 638 |
| Tensile Modulus, 50 mm/min | 16370 | MPa | ASTM D 638 |
| Flexural Stress | 136 | MPa | ASTM D 790 |
| Flexural Modulus | 15610 | MPa | ASTM D 790 |
| Tensile Stress, break | 84 | MPa | ISO 527 |
| Tensile Strain, break | 0.8 | % | ISO 527 |
| Tensile Modulus, 1 mm/min | 16250 | MPa | ISO 527 |
| Flexural Stress | 137 | MPa | ISO 178 |
| Flexural Modulus | 14850 | MPa | ISO 178 |
| IMPACT | Value | Unit | Standard |
| Izod Impact, unnotched, 23°C | 170 | J/m | ASTM D 4812 |
| Izod Impact, notched, 23°C | 16 | J/m | ASTM D 256 |
| Izod Impact, unnotched 80*10*4 +23°C | 14 | kJ/m² | ISO 180/1U |
| Izod Impact, notched 80*10*4 +23°C | 4 | kJ/m² | ISO 180/1A |
| THERMAL | Value | Unit | Standard |
| Thermal Conductivity | 1.05 | W/m-°C | ASTM E 1530 |
| HDT/Bf, 0.45 MPa Flatw 80*10*4 sp=64mm | 264 | °C | ISO 75/Bf |
| HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm | 202 | °C | ISO 75/Af |
| PHYSICAL | Value | Unit | Standard |
| Density | 2.208 | g/cm³ | ASTM D 792 |
| Mold Shrinkage, flow, 24 hrs | 0.5 | % | ASTM D 955 |
| Mold Shrinkage, xflow, 24 hrs | 0.7 | % | ASTM D 955 |
| Mold Shrinkage, flow, 24 hrs | 0.45 | % | ISO 294 |
| Mold Shrinkage, xflow, 24 hrs | 0.71 | % | ISO 294 |
| Wear Factor Washer | 4141 | 10^-10 in^5-min/ft-lb-hr | ASTM D 3702 Modified |
| Dynamic COF | 0.51 | - | ASTM D 3702 Modified |
| Static COF | 0.52 | - | ASTM D 3702 Modified |
| Density | 2.2 | g/cm³ | ISO 1183 |
| Source GMD, last updated:09/29/2004 | |||
| Parameter | ||
| Injection Molding | Value | Unit |
| Drying Temperature | 120 - 150 | °C |
| Drying Time | 4 | hrs |
| Melt Temperature | 315 - 320 | °C |
| Front - Zone 3 Temperature | 330 - 345 | °C |
| Middle - Zone 2 Temperature | 320 - 330 | °C |
| Rear - Zone 1 Temperature | 305 - 315 | °C |
| Mold Temperature | 140 - 165 | °C |
| Back Pressure | 0.2 - 0.3 | MPa |
| Screw Speed | 30 - 60 | rpm |
| Source GMD, last updated:09/29/2004 | ||
